Introduction

We all use Postman to manually test APIs, but if we want to automate API testing using the command line, we should try Postman CLI. With the launch of Postman v10, the product team has simplified the lives of users by automatically generating the CLI commands that enable us to test & run the collections in any CI/CD pipelines. The good news is that all test results will instantly sync to Postman, allowing users to conduct additional testing failure analysis and troubleshooting using Postman Collection Runs.

Installation of Postman CLI

  • Run the below command in the terminal based on your Operating System

    Windows Installation

    powershell.exe -NoProfile -InputFormat None -ExecutionPolicy AllSigned -Command "[System.Net.ServicePointManager]::SecurityProtocol = 3072; iex ((New-Object System.Net.WebClient).DownloadString('https://dl-cli.pstmn.io/install/win64.ps1'))"


    Mac (Intel) Installation

      curl -o- "https://dl-cli.pstmn.io/install/osx_64.sh" | sh


    Linux Installation

    curl -o- "https://dl-cli.pstmn.io/install/linux64.sh" | sh


    Let's check the version postman -v

    CLI Command version.png

Run collections using terminal

We can now run the collections locally as Postman CLI has been installed

You need the API key to log in on Postman CLI and get authorization for running your collections

Step 1 : Generate your Postman API Key or you can use existing one as below


  • Generate key

Generate API Key.png

  • Use Existing key

Use Existing Key.png

Step 2 : Copy the auto generated command from Postman CLI and paste it to your terminal and hit Enter

The process will first authenticate you using your API Key, run the collections, and log you out of the terminal

CLI Flow.png

CLI run.png

Step 3 : Users can further investigate test failures on the Postman using the run data link generated on the terminal.

Results Check.gif

Step 4 : postman logout

CLI Logout.png

๐Ÿ’กBonus Tips

๐Ÿ“Œ How do you run a collection N times?

Pass the Iteration count using the -n option, as shown below.

postman login --with-api-key <<Provide your API Key>>
postman collection run <<Collection ID>> - n <<Iteration Count>>

Iterations Runs.gif

๐Ÿ“Œ If we check and uncheck the collection folders or rearrange the Requests in Runner, how can we auto generate the CLI script?

Let's see how Postman does this magic for us


Run collections using GitHub Actions

Postman & Github.png

Once the commands have been tested locally, we are ready to use them in our CI/CD pipelines. This enables us to run our tests and validations on CI/CD using Postman CLI configuration and seamlessly link the results back to Postman.

Step 1 : Click Configure Command under Run on CI/CD section

CICD Configure.png

Step 2 : Select configurations such as Collection, Environment, CI/CD Provider OS for CI/CD will get auto selected with respect to Provider. Copy the auto generated script.

CLI Configuration.gif

Step 3 : Paste the script into GitHub Actions pipeline. Ex: dev-pipeline.yml file

Feel free to experiment with the yaml script by adding Events, Jobs, Actions and Runners to the workflow


Step 4 : Save the Postman API Key as a secret environment variable in GitHub repo to prevent exposure.


Step 5 : Run this workflow manually from the Actions tab



Step 6 : Check the results using the run data link displayed in the pipeline logs


This workflow will be triggered automatically for every push or pull request event made for the "main" branch

Collection Runs

We can view the information of previous collection runs done via Collection Runner or Postman CLI by selecting the Runs tab under the collections. You can share the report with your team member's using the share option if you want them to review the failed tests, if they are already part of the workspace they can access the reports directly without the invite.


Conclusion

Hopefully you found it interesting to learn how to use Postman CLI for running the collections locally, using CI/CD pipelines & checking the reports via Postman Runs.
